Copper Bonded Threaded Earthing Rod – Durable Earthing System
Copper Bonded Threaded Earthing Rod is an efficient and durable earthing solution to ensure long life protection against electrical surges, lightning and fault currents. Formed through a composite of steel and copper, the rod delivers excellent conductivity with unmatched sturdiness, guaranteeing dependable earthing. Commonly installed in domestic, corporate, and industrial projects, it is chosen for durability, safety, and consistent performance over time.
What is a Copper Bonded Threaded Earthing Rod?
Copper Bonded Threaded Earthing Rod is a steel rod that has been molecularly bonded to copper by the application of a cutting-edge electroplating technology. It contributes to high resistance to corrosion and outstanding conductivity of the copper layer, whereas the steel core is highly mechanically strong to resist driving forces during installation.
The threading on the Copper Bonded Earthing Rod enables it to be used with couplers and driving heads, so that several rods can be stacked together to get the required depth. This property renders it suitable for different soil states and provides successful fault current dissipation.
Technical Specification of Copper Bonded Threaded Earthing Rod
Designed to the exact dimensions, tensile strength and copper thickness to provide the best performance.
- Material composition: Low-carbon steel core bonded with high-purity copper.
- Length Choices: Standard length sizes are between 1.2 meters and 3 meters, with longer extensions through coupling rods.
- Threading Type: Threading is machine-cut precision, to be extended and mounted easily.
- Copper Bond Thickness: The thickness varies between 100-250 microns according to design.
- Tensile Strength: High tensile strength, usually above 600 N/mm².
- Conductivity: Excellent electrical conductivity as a result of copper bonding.
- Corrosion Resistance: Thick copper clad and molecular bonded.
- Standards Compliance: Made to conform to international earthing and safety standards.
Key Features of Copper Bonded Threaded Earthing Rod
With features that guarantee durability, efficiency and installation simplicity.
- Strong steel core for high tensile strength and durability
- Copper coating with great bonding, resulting in extended service life.
- Easy joining with couplers and driving accessories. Precision threading.
- Resistant to corrosion, even in highly aggressive soil conditions
- Copper Bonded Threaded Earthing Rod gives low earth resistance and is consistent.
- Easy setup and maximum deep digging without bending or breaking.
- Thick copper bonding results in high conductivity.
- Environment-friendly and maintenance-free design
Benefits of Copper Bonded Threaded Earthing Rod
Offers long-term safety, cost-effectiveness, and stable earthing in all conditions.
- Improved Safety: Safeguards humans, equipment and property by offering effective fault current dissipation.
- Extended Life Cycle: The copper bonding will resist the corrosion of the steel core and provide decades of service.
- Cost-Efficiency: The initial investment can be more than simple rods, but the low maintenance and durability are cost-effective over the long term.
- Reliable Earthing: Consistently resistant, and therefore can be used in different soil conditions.
- Installation Flexibility: The threaded design gives the ability to extend the rods to the desired depth without compromising strength.
- Interchangeability: Operates efficiently with couplers, driving heads, and clamps so that it can fit into a variety of configurations.
Why Choose This Product Copper Bonded Threaded Earthing Rod?
The safety and performance of any electrical installation are heavily dependent on the selection of the earthing system. The strengths, conductivity and durability of a Copper Bonded Threaded Earthing Rod make it unique. As opposed to plain steel or galvanized rod, they have high corrosion resistance, which is essential to long-term grounding systems.
They are also a good option since their threaded design guarantees adaptability during installation and prevents loosening with time. Manu India Earthing provides these rods as a reliable and effective earthing solution, whether it is in a large industrial setup, in critical infrastructure, or even in a residential setup.
Applications & Use Cases of Copper Bonded Threaded Earthing Rod
Commonly used in industry, infrastructure and residential construction as safe grounding.
- Residential Buildings: Guarantees lightning safety and electrical malfunction.
- Commercial Complexes: These are used to ground sensitive electrical and electronic equipment.
- Industrial Plants: These are used to cover heavy machinery and guard against downtime due to electrical surges.
- Telecommunication Tower: It is a tower mounted on a firm surface to shield the fragile telecommunication devices.
- Power Transmission & Distribution Systems: Ensures safety and system reliability.
- Renewable Energy Projects: They find their applications in solar power plants and wind turbines to dissipate fault current.
- Data Centers / IT Hubs: Safeguard the servers and the networking infrastructure against power outages.
FAQs
Threaded rods can easily be extended with couplers, and unthreaded rods are used where single-length rods are needed.
Yes, the thread design enables more than one rod to be coupled to give the depth more in hard soil conditions.
Yes, they transpire well in the majority of soils, such as rocky, sandy, and corrosive soils.
No, they are built to be maintenance-free and give uniform performance during a long period of service.
Yes, once properly installed, these rods do not need much or any maintenance due to their resistant copper coating and solid steel structure.
Absolutely. They are well-liked deep-installation lampposts because they can be smoothly driven into the ground without exposed threads that can be damaged during installation.
Our Products
Copper Bonded Threaded Earthing Rod
Contact Info
Our team is ever ready to address any queries! Please call the given number to avail our services!
+91 73898 49969,
+91 72250 22268,
+91 72250 22286
24/7 Support for Your Business
Info File
Copper Bonded Threaded Earthing Rod
A Copper Bonded Threaded Earthing Rod is a type of grounding electrode made from a high-tensile steel core coated with a layer of copper. The threaded design allows for easy connection between multiple rods, providing the flexibility to extend the length of the grounding system as needed. These Earthing rods are designed to offer superior conductivity, durability, and resistance to corrosion, making them an ideal choice for reliable and long-lasting earthing solutions.
Features
- Threaded Design: Allows easy coupling with other rods for extended grounding systems.
- High-Tensile Steel Core: Provides strength and durability for demanding installations.
- Electrolytic Copper Coating: Ensures superior conductivity and resistance to corrosion.
- Corrosion-Resistant: The copper layer prevents rust and degradation over time.
- Variety of Sizes: Available in different lengths and diameters to meet specific grounding needs.
Applications
Copper Bonded Threaded Earth Rods are commonly used in large-scale grounding systems for power stations, substations, and industrial facilities, where deep and reliable grounding is necessary. They are also used in telecommunication towers, renewable energy systems like solar panels and wind turbines, and oil and gas installations to ensure safety and efficient electrical grounding. Their threaded design makes them ideal for situations where extended grounding rods are required, providing flexibility for different soil conditions.
Advantages
- Superior Conductivity: Ensures efficient grounding and protection against electrical faults.
- Durability: The copper coating offers long-term protection against corrosion, increasing the lifespan of the rod.
- Flexibility: The threaded design allows for easy extension of the grounding system, suitable for various installation depths.
- High Strength: The steel core ensures the rod can withstand mechanical stress during installation and environmental conditions.
- Easy Installation: Threaded coupling simplifies the installation process, saving time and effort.
| Road Dia (mm) | Thread Size (mm) | Total Length (mm) |
|---|---|---|
| 12 | 1/2'' | 1000 |
| 12 | 1/2'' | 2000 |
| 12 | 1/2'' | 3000 |
| 14 | 5/8'' | 1000 |
| 14 | 5/8'' | 2000 |
| 14 | 5/8'' | 3000 |
| 16 | 5/8'' | 1000 |
| 16 | 5/8'' | 2000 |
| 16 | 5/8'' | 3000 |
| 17 | 3/4'' | 1000 |
| 17 | 3/4'' | 2000 |
| 17 | 3/4'' | 3000 |
| 19 | 3/4'' | 1000 |
| 19 | 3/4'' | 2000 |
| 19 | 3/4'' | 3000 |
| 25 | 1'' | 1000 |
| 25 | 1'' | 2000 |
| 25 | 1'' | 3000 |
| *Sizes can be customized | ||
