Diagonal Clamp

Diagonal Clamps

Diagonal Clamps are specialized clamps designed to securely hold or connect conductors, cables, or components at an angled or diagonal position. These clamps are ideal for applications where traditional straight alignment is not feasible, such as angled installations in electrical systems or structural frameworks. They ensure reliable mechanical and electrical connections while accommodating non-linear configurations.

Features

  • Angled Design: Specifically crafted to hold components at a diagonal orientation, ensuring secure alignment.
  • High Durability: Made from robust materials like galvanized steel, copper, or stainless steel, providing excellent strength and corrosion resistance.
  • Versatile Compatibility: Can accommodate a range of conductor sizes and types, making them suitable for diverse applications.
  • Enhanced Grip: Equipped with secure locking mechanisms to prevent slippage or movement under tension.
  • Weather-Resistant: Suitable for indoor and outdoor installations, with coatings to withstand harsh environmental conditions.

Applications

Diagonal clamps are widely used in power transmission lines, grounding systems, telecommunication towers, construction frameworks, and industrial setups. They are also utilized in solar panel installations, where angled connections are required for mounting and wiring.

Advantages

  • Flexibility: Supports angled or non-linear configurations, making it suitable for complex installations.
  • Reliable Performance: Ensures secure and stable connections even under mechanical stress or environmental challenges.
  • Corrosion Resistance: Coated or treated to resist rust and deterioration in outdoor environments.
  • Easy Installation: Simple to attach using bolts or screws, saving time and effort during assembly.
  • Versatile Usage: Compatible with multiple conductor types and sizes, providing adaptability for various applications.
MaterialStainless Steel
Grade304
StandardIS-IEC 62305 / 62561
Impulse Current100 kA 10/350 µs
Suitability8 – 10 mm
