The G.I. Pipe Earthing Electrode improves the integrity and safety of electrical installations,
which makes it an essential feature of an effective grounding system. Manufactured with care
and consistency, this electrode can be relied upon to effectively dissipate fault-current into the
ground to protect structures, equipment and lives. It is one of the Manu India Earthing
catalogues of chemical earthing electrodes, manufactured by a leading Chemical Earthing
Manufacturer to withstand the environment, provide high conductivity, and ensure easy
installation.
A G.I. Pipe Earthing Electrode is an earthing electrode in the form of a hollow pipe made of galvanized iron and often has holes along its length. Such perforations enhance contact with the soil and enable the circulation of moisture around the electrode, which reduces the resistance.
The electrode is set up vertically into an earthing pit filled with backfill compounds akin to charcoal, bentonite, or salt to promote conductivity. When in position, a secure, stable grounding system is achieved, and a stray or fault current is safely dumped into the ground.
This is appropriate when ruggedness and high-reliability earthing are required, but the cost and toughness must also be economically balanced.
Specifications may differ, based on project needs, but here are some commonly available G.I. Pipe Earthing Electrode specifications:
Specification | Typical Range / Detail |
Material | Galvanized Iron (GI) |
Pipe Diameter | Commonly 50 mm; can vary as required |
Inner/Outer Strips | GI or Copper-lined strips (e.g., 25×3 mm) |
Length | Standard lengths between 2–3 m |
Terminal Size | Typically, 50×6 mm; variations possible |
Corrosion Protection | Zinc galvanization with custom thickness |
Industry Compliance | Meets earthing requirements (e.g., IS 3043) |
These details reflect typical embodiments in the industry and on supplier sites similar to your offering.
G.I. Pipe Earthing Electrode is a safe choice due to the various benefits that come with it. These features make the product choice redeemable and needs-based.
● Safety Assurance: Safeguards electrical systems and connected devices against sudden current surges.
● Economic Choice: It is a proven, inexpensive earthing material compared to a copper alternative.
● Versatility: Applicable in the industry of residential, industrial, and commercial sectors.
● Sustained Performance: Holds steady levels of resistance throughout the years of service.
● Eco-Friendly Option: Works effectively with non-hazardous backfill materials, which minimize environmental hazards.
By choosing the G.I. Pipe Earthing Electrode, you will be choosing a tried and tested, economical and durable earthing option. Its galvanized design guarantees long life, though the design provides a grounding characteristic of efficiency in many conditions. It is industry-wide recognized and commonly complies with the statutorily provided grounding requirements (e.g., multi-pit earthing arrangement as defined in national or regional safety regulations).
The G.I. Pipe Earthing Electrode is suitable for a wide variety of locations, such as:
Be it in a rural, urban, or industrial setting, this electrode can suit differing site requirements.
Although copper provides low resistance, galvanizing of G.I. offers a cost-effective option. Projects easily adapt to most standard installations.
The standard lengths are 23 m and 3 m, and the pipe diameters usually include 50 mm and terminal strips of 25 by 3 mm and so on. Custom sizes on a project basis
To achieve the best conductivity, conductive earthing compounds or mixtures of charcoal/salt are recommended where soils are dry or rocky.
Galvanized protection normally guarantees several years of trouble-free service depending on soils and environmental conditions.
No design makes quick installation in pits possible with clamp and strip assemblies in use with earthings.
It is erected vertically in an earthing pit that is stiffened up with porches, with its enclosures backfilled with conductivity-enhancing compounds such as char, bentonite or salt.
Generally, no. Being crystal electrically, when installed and utilized, the electrode loses its structural and conductive characteristics once taken out.
Our team is ever ready to address any queries! Please call the given number to avail our services!
24/7 Support for Your Business
A GI (Galvanized Iron) Pipe Earthing Electrode is a grounding electrode made from galvanized iron pipes that are coated with a layer of zinc to provide corrosion resistance. This type of electrode is used to ensure effective grounding in electrical systems by providing a safe path for fault currents to flow into the earth. GI Pipe Earthing Electrodes are often chosen for their durability and cost-effectiveness, making them a popular choice for various industrial, commercial, and residential applications.
| Pipe Dia (mm) | Inner Strip (mm) / Pipe (OD) | Total Length (mm) | Terminal Size (mm) |
|---|---|---|---|
| 48 | 20 x 3 / 25 | 1000 | 40x6 |
| 48 | 20 x 3 / 25 | 2000 | 40x6 |
| 48 | 20 x 3 / 25 | 3000 | 40x6 |
| 58 | 25 x 3 / 32 | 1000 | 50x6 |
| 58 | 25 x 3 / 32 | 2000 | 50x6 |
| 58 | 25 x 3 / 32 | 3000 | 50x6 |
| 76 | 25 x 3 / 32 | 1000 | 50x6 |
| 76 | 25 x 3 / 32 | 2000 | 50x6 |
| 76 | 25 x 3 / 32 | 3000 | 50x6 |
| 88 | 32 x 5 / 48 | 1000 | 50x6 |
| 88 | 32 x 5 / 48 | 2000 | 50x6 |
| 88 | 32 x 5 / 48 | 3000 | 50x6 |
| *Sizes can be customized | |||
