A Hot Dip GI( galvanized iron) pipe earthing electrode is manufactured from the finest quality raw material and is ideal for various rugged applications, as these need the least conservation and low-cost technology. This process enhances the life of the pipe and makes it ideal for operations that bear strength and erosion resistance.
Grounding and earthing systems are fundamental requirements to safeguard human life, electrical devices, and buildings against lightning and faults. As an option to numerous earthen electrodes, the Hot Dip GI Pipe Earthing Electrode, offered by leading Electrode Manufacturers in India—is the most reliable and long-lasting solution for the industrial and commercial sectors.
A Hot Dip GI pipe earthing electrode is made of galvanized iron pipe. The process is hot-dip galvanization, which involves applying a thin layer of zinc to GI pipe to prevent corrosion. This process enhances the life of the pipe and makes it ideal for applications that require strength and corrosion resistance.
Hot-dip galvanized pipe earth electrode applications include a wide range of industries and sectors:
There are still many traditional methods like plate earthing and rod earthing, but there are several advantages that you can avail through Hot Dip GI pipe earthing electrode:
Another highlight for these electrodes is that they have a hot-dip galvanized effect, which can help the steel pipe from being damaged by erosion. With a zinc coating consistence ranging from 80 to 100 microns, these electrodes are ideal for installation in moisture-rich and chemically active soils. This greatly increases the service life of the earthing system.
Offers superior durability and is ideal for heavy-duty work environments. Unlike bare rods or plates, hot-dip galvanizing provides long-term protection against rust and corrosion. A hot-dip GI pipe earthing electrode can last 10 to 15 years or more, with minimal depreciation. This minimizes replacements and saves you significant operational costs in the long run.
They are easy to handle and can be transported and installed in any corner of the world. With Expert Installation Services, they can be driven straight into the ground or installed with backfill, depending on your soil type. The installation is quicker and less labor-intensive than that of the conventional plate earth system.
Provides an affordable and dependable grounding solution. Hot-dip galvanized pipe earth electrodes are comparatively less costly in comparison to copper electrodes but offer good performance. For projects with budget constraints, they provide a balance between quality and affordability, especially in outdoor installations such as industrial plants or telecom towers!
At Manu India Earthing, we are committed to delivering top-quality earthing solutions that ensure safety, durability, and performance. This is why our clients trust our GI Hot Dip Earthing Electrode—the industries that lead trust us.
The normal life of a hot-dip GI electrode is 10–15 years under normal conditions of soil resistivity and moisture.
In the process of installing the GI Earthing Electrode, a bore hole is drilled, and the electrode is inserted perpendicular to the ground while a backfill chemical is placed around the electrode to lower the resistance of the soil and to provide conduction.
Yes, we provide you with a complete earthing solution, from product delivery to site survey to installation by our trained technicians.
Our team is ever ready to address any queries! Please call the given number to avail our services!
24/7 Support for Your Business
A Hot Dip GI (Galvanized Iron) Pipe Earthing Electrode is a grounding solution made from galvanized iron pipes that undergo a hot-dip galvanizing process, where the pipe is dipped in molten zinc to create a thick and durable zinc coating. This process enhances the corrosion resistance of the pipe, making it highly suitable for applications where long-term durability is essential. Hot Dip GI Pipe Earthing Electrodes provide reliable grounding by offering a low-resistance path for fault currents to safely dissipate into the earth.
Hot Dip GI Pipe Earthing Electrodes are widely used in electrical grounding systems, telecommunication installations, solar energy systems, industrial facilities, power stations, and substations. They are also commonly used in lightning protection systems, oil and gas industries, and residential and commercial buildings to ensure a safe and efficient grounding system.
| Pipe Dia (mm) | Inner Strip (mm) / Pipe (OD) | Total Length (mm) | Terminal Size (mm) |
|---|---|---|---|
| 48 | 20 x 3 / 25 | 1000 | 40x6 |
| 48 | 20 x 3 / 25 | 2000 | 40x6 |
| 48 | 20 x 3 / 25 | 3000 | 40x6 |
| 58 | 25 x 3 / 32 | 1000 | 50x6 |
| 58 | 25 x 3 / 32 | 2000 | 50x6 |
| 58 | 25 x 3 / 32 | 3000 | 50x6 |
| 76 | 25 x 3 / 32 | 1000 | 50x6 |
| 76 | 25 x 3 / 32 | 2000 | 50x6 |
| 76 | 25 x 3 / 32 | 3000 | 50x6 |
| 88 | 32 x 5 / 48 | 1000 | 50x6 |
| 88 | 32 x 5 / 48 | 2000 | 50x6 |
| 88 | 32 x 5 / 48 | 3000 | 50x6 |
| *Sizes can be customized | |||
